IKA® Ultra TURRAX® T 65 Digital Disperser, 2 - 50 L, 4234501

Ahorrar $2,673.90
IKA® Works, IncSKU: 0004234501

WORLDWIDE SHIPPING AVAILABLE.
PLEASE
CONTACT US

Precio:
Precio de venta$13,369.47 USD Precio habitual$16,043.37 USD

Gastos de envío calculados en la caja

Condition: Brand new with manufacturer's warranty

Disponibilidad: Envío directo desde el fabricante. Sujeto a disponibilidad de existencias.

Gastos estimados de envío

Descripción

Extremely powerful dispersing instrument for volumes from 2 - 50 l (H2O) for typical pilot plant stations with digital speed display. It offers a wide speed range from 1000 Ð 9,500 rpm that enables users to work at high circumferential speeds even with small rotor diameters. Three rotor-stator configurations guarantee a wide range of applications. Reproducible operations due to constant speed even with changes in viscosities.

  • Digital speed display
  • Electronic speed control
  • Electronic overload protection
  • Plug-in connectors facilitate exchange of dispersing elements
  • Optional stainless steel dispersing elements for use under vacuum and pressure
  • Error code display
  • Mains cable (2.5 m) and SI 400 safety switch are available as accessories (not included with delivery)

The device requires a 3-phase electricity supply in order to operate. The connection of the unit to the power supply must be done by a qualified electrician. Wiring diagrams are included in the manual for reference.

*Requires 3 x 230V electrical wiring

Package Includes:

  • T 65 digital ULTRA-TURRAX®
  • Rotor wrench
  • Hook wrench
  • Shaft wrench
  • Cable gland for switch cable (2 pcs.)
  • Hexagon L-wrench

                  Country of Origin:ÊGermany

                  Warranty:ÊComes with 2+1 Year Warranty. See detailsÊhere

                  Motor rating input 1800 W
                  Motor rating output 1500 W
                  Volume range (H2O) 2 - 50 l
                  Viscosity max. 5000 mPas
                  Speed range 1000 - 9500 rpm
                  Speed deviation 3 %
                  Speed adjustment stepless
                  Speed display 7 segment LED
                  Noise without element 75 dB(A)
                  Process type batch
                  Dimensions (W x H x D) 300 x 390 x 400 mm
                  Weight 30 kg
                  Permissible ambient temperature 5 - 40 °C
                  Permissible relative humidity 80 %
                  Protection class according to DIN EN 60529 IP 54
                  Voltage 3 x 230 V
                  Frequency 60 Hz
                  Power input 1800 W
