Descripción
Extremely powerful dispersing instrument for volumes from 2 - 50 l (H2O) for typical pilot plant stations with digital speed display. It offers a wide speed range from 1000 – 9,500 rpm that enables users to work at high circumferential speeds even with small rotor diameters. Three rotor-stator configurations guarantee a wide range of applications. Reproducible operations due to constant speed even with changes in viscosities.
- Digital speed display
- Electronic speed control
- Electronic overload protection
- Plug-in connectors facilitate exchange of dispersing elements
- Optional stainless steel dispersing elements for use under vacuum and pressure
- Error code display
- Mains cable (2.5 m) and SI 400 safety switch are available as accessories (not included with delivery)
The device requires a 3-phase electricity supply in order to operate. The connection of the unit to the power supply must be done by a qualified electrician. Wiring diagrams are included in the manual for reference.
*Requires 3 x 230V electrical wiring
Package Includes:
- T 65 digital ULTRA-TURRAX®
- Rotor wrench
- Hook wrench
- Shaft wrench
- Cable gland for switch cable (2 pcs.)
- Hexagon L-wrench
Country of Origin: Germany
Warranty: Comes with 2+1 Year Warranty. See details here
Motor rating input | 1800 W |
Motor rating output | 1500 W |
Volume range (H2O) | 2 - 50 l |
Viscosity max. | 5000 mPas |
Speed range | 1000 - 9500 rpm |
Speed deviation | 3 % |
Speed adjustment | stepless |
Speed display | 7 segment LED |
Noise without element | 75 dB(A) |
Process type | batch |
Dimensions (W x H x D) | 300 x 390 x 400 mm |
Weight | 30 kg |
Permissible ambient temperature | 5 - 40 °C |
Permissible relative humidity | 80 % |
Protection class according to DIN EN 60529 | IP 54 |
Voltage | 3 x 230 V |
Frequency | 60 Hz |
Power input | 1800 W |
