IKA RV 10 Auto PRO FLEX® Rotary Evaporator w/o Glassware, 10005197

Save 12%
IKA Works, IncSKU: 10005197

Price:
Sale price$11,583.86 USD Regular price$13,089.76 USD

Condition: Brand new with manufacturer's warranty

Availability: Drop ships from manufacturer. Subject to stock availability.

Estimate shipping

Payment & Security

American Express Apple Pay Diners Club Discover Meta Pay Google Pay Mastercard Shop Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Description

The completely revised RV 10 auto is the flagship of the IKA Rotation Evaporator product line. Its impressive features include an innovative handling concept with a bright, high-contrast, TFT, color-graphic control panel, an integrated vacuum controller, cooling water monitoring and mature safety standards.

The RV 10 auto offer all properties required for efficient, safe, and cost-effective operations. These include automatic control of the vacuum and cooling water volume. Its intuitive handling concept quickly leads its users to their desired results in every application. Thanks to its extended ramp programming capability, the RV 10 auto allows users to carry out customized procedures.

Other innovative features, such as smooth start, interval mode, right-left operation in interval mode, or the timer function for time-lapse tests, make everyday work in the laboratory much easier. Safety is ensured by the motorized lift with safety-stop function that automatically lifts the evaporation flask out of the heating bath in the case of power failure.

Additional safety for users is provided by individually adjustable temperature safety circuits, protection against boiling dry, adjustable end-point recognition to prevent glass breakage, and a locking function. The receiving flask and the condenser are also available in coated versions.

The USB port or the RS-232 interface enable remote control with the IKA “labworldsoft” software package and an update option with the firmware update tool. The device comes complete with vacuum hoses and hose connectors for your in-house cooling water supply. The new IKA Vacstar digital included in the package is controlled directly from the drive unit of the RV 10 auto via the data cable provided.

    Features:

    • New: 4 l heating bath
    • automatic boiling point detection
    • integrated vacuum controller
    • integrated solvent library with 40 preset solvents and expansion option
    • bright, high-contrast, TFT, color-graphic control panel
    • universal safety heating bath
    • optimized heating bath volume for rapid achievement of working temperature
    • heating bath with ergonomic handles
    • temperature safety circuit
    • boil-dry protection
    • condenser with 1500 cm² cooling surface and low space requirements
    • evaporation flasks available with coated glass
    • intuitive handling concept with simple menu navigation
    • programming option for up to ten individual procedures
    • smooth start
    • right or left rotation
    • timer function
    • end-point recognition
    • push-off mechanism for tightly-fitting flasks
    • digital interfaces: USB port and RS-232 interface for remote control
    • multi-language operating system
    • automatic cooling water management
    • automatic ventilation
    • automatic heating bath management

                Package Includes:

                • RV 10 auto
                • HB digital S099
                • VACSTAR digital
                • RV 05.10 Balljoint clamp
                • RV 10.89 Clamp NS 24
                • RV 10.73 Vapor tube (NS 24/40)
                • RV 10.8001 Seal
                • Vacuum hose (2 x 0.55 m)
                • Water discharge hose (1 x 1 m)
                • Water discharge hose (1 x 1 m)
                • USB cable

                Country of Origin: Germany

                Warranty: Comes with 2+3 Year Warranty. See details here

                Type of cooling without condenser
                Speed range 5 - 300 rpm
                Reversible direction of rotation yes
                Speed tolerance set rotation speed < 100rpm ±1 rpm
                Speed tolerance set rotation speed > 100rpm ±1 %
                Lift Motor
                Stroke 140 mm
                Heating temperature range room temp. - 180 °C
                Heat output 1350 W
                Set temperature resolution ±1 K
                Filling volume max. 4 l
                Vacuum controller integrated yes
                Timer yes
                Dimensions (W x H x D) 500 x 430 x 440 mm
                Weight 18.6 kg
                Permissible ambient temperature 5 - 40 °C
                Permissible relative humidity 80 %
                Protection class according to DIN EN 60529 IP 20
                RS 232 interface yes
                USB interface yes
                Analog output yes
                Voltage 100 - 240 V
                Frequency 50/60 Hz
                Power input 100 W
                Power input standby 3.3 W
