Description
Regardless of whether samples are hard, soft or fibrous – the IKA MultiDrive crusher can perform a wide range of crushing tasks involving coarse and fine crushing, thanks to the variety of vessels available (vessels not included in delivery). With the MultiDrive basic it is possible to mix or grind. There is a USB interface available for easy actuation and documentation respectively. In combination with the milling chamber MI 250 MultiDrive basic replaces your M 20 mill.
High performance
Excellent crushing performance is guaranteed by a combination of
variable rotational speeds, ranging from 3000 rpm to 20 000 rpm,
and a 1000 Watt output.
Interval operation
The option of interval programming is simple to activate at the
press of a button. Interval operation is an asset during the coarse
crushing of hard samples or for extra thorough blending.
Integrated cooling
A cooling system is integrated in the milling cup, which allows
indirect heat dissipation. Thus, coolant and sample remain separate.
Variety of vessels (accessory)
MultiDrive provides the right vessel for each grinding task.
Vessels don't belong to the scope of delivery.
Package Includes:
- IKA MultiDrive basic
- Socket wrench
- Disassembly tool 1
- Disassembly tool 2
- Cleaning brush
- USB Cable - USB A to Micro-B, 2 m
Country of Origin: Germany
Warranty: Comes with 2+1 Year Warranty. See details here
| Process type | batch |
| Operating principle | cutting/impact/blending/dispersing |
| Motor rating input | 1000 W |
| Motor rating output | 800 W |
| Speed range | 3000 - 20000 rpm |
| Speed deviation | ±5 % |
| Power-ON time | 5 min |
| Power-OFF time | 10 min |
| Motor principle | Brushless DC |
| Display | 7 segment LED |
| Vessels detection | yes |
| Dimensions (W x H x D) | 300 x 350 x 250 mm |
| Weight | 8.5 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 31 |
| USB interface | yes |
| Voltage | 100 - 120 V |
| Frequency | 50/60 Hz |
| Power input | 1000 W |
