Description
Modularly configured laboratory reactor for the optimization and reproduction of various chemical reactions, mixing and homogenization processes on a lab scale.
The system is particularly characterized by the agitator mounting, which allows for a safe transfer of the higher motor torque.
ULTRA-TURRAX® dispersers, temperature sensors, flow breakers and other accessories can be attached to the open ports of the reactor cover.
Features:
- Suitable for vacuum operation
- Solvent- and temperature-resistant perfluoroelastomer (FFPM) seals come into contact with sample
- Infinitely variable speed
- Torque trend display for measuring changes in viscosity
- Microprocessor-controlled speed regulation, enables steady speed, also under load
- Removable WiCo (wireless controller) for remote and safe use in a fume hood
The LR-2.ST laboratory reactor system consists of:
- Stand system
- EUROSTAR 200 control P4 laboratory stirrer with higher torque
- Safety
- Reactor cover
Package Includes:
- LR-2.ST
- LR-2.SI
- HEAD,REACTOR,LR2.10
- EUROSTAR 200 P4 control
Country of Origin: Germany
Warranty: Comes with 2+1 Year Warranty. See details here
| Useable volume | 500 - 2000 ml |
| Working temperature | room temp. - 230 °C |
| Attainable vacuum | 25 mbar |
| Viscosity max. | 150000 mPas |
| Speed range | 8 - 290 rpm |
| Telescope stand stroke | 390 mm |
| Material in contact with medium | borosilicate glass, FFPM, PTFE, steel 1.4571 |
| Reactor vessel openings (units/standard) | 3/NS 29/32 2/NS 14/23 |
| Torque max. at stirring shaft | 660 Ncm |
| Dimensions (W x H x D) | 460 x 1240 x 430 mm |
| Weight | 25 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
