Descripción

The AOD 1 is used for oxidative decomposition of solid and liquid organic and partially inorganic samples under pressure in a closed system.

The system consists of:
  • AOD 1.1 Decomposition vessel,
  • C 48 Oxygen station,
  • AOD 1.2 External ignition unit,
  • AOD 1.11 Control standard (50 ml)
In order to operate the decomposition system properly it is required to have a protective device in place in order to safely ignite the sample.
If such protective device is already in place, please add the accessory AOD 1.3 remote ignition head.
If no protective device is in place, our AOD 1.3 protective device could be chosen for example.
  • Quantitative decomposition of all halogens, sulfur, as well as volatile metals, e.g. As and Hg
  • Absorption of the combustion products in an aqueous medium
  • Catalytic support of the oxidation process with auto-regenerating catalytic inner surface of the decomposition vessel
  • Pressure vessel of high-grade stainless steel
  • Decomposition temperature up to 1200 °C
  • Max. operating pressure during decomposition 195 bar
  • Decomposition time < 3 min
  • The decomposition vessel can be changed over to use combustible crucibles C 14
  • Control standards for Cl, S ( AOD 1.11)
  • Introduction of the combustion gases into the absorption solution via venting station C 7030
Principle and function are based on the method of the combustion in the bomb calorimeter and validated according DIN 51577-1

Other relevant standards are for example:
  • DIN / EN 14582, determination characteristics of waste, halogen and sulfur content
  • DIN 51527, Testing of solid samples, determination of chlorine content

Country of Origin: Germany

Warranty: Comes with 1+1 Year Warranty. See details here

Decomposition time 3 min
Core temperature max. 1200 °C
Pressure max. 195 bar
Chamber volume 210 ml
Oxygen operating pressure max. 40 bar
Dimensions (W x H x D) 400 x 480 x 260 mm
Weight 12.5 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity 80 %
Protection class according to DIN EN 60529 IP 20
Voltage 115 V
Frequency 50/60 Hz
Power input 45 W
