Description
Crushing without cross-contamination - this is possible with the MultiDrive control package including autoclavable disposable tubes MT 150 and the required TC 1 protective housing for dry samples.
MT 150 is a disposable tube with a typical stainless steel beater. The plastic milling tube can be autoclaved. This effectively prevents cross-contamination even if it is used multiple times. An integrated RFID chip simultaneously stores and limits the lifespan of the milling tube. 5 spare seals are included in the scope of delivery. By replacing the seal, the service life of the grinding chamber can be extended. The disposable tube can only be operated with the TC 1 protective housing which is also included in the scope of delivery.
MultiDrive universal crusher can perform a wide range of crushing tasks involving coarse and fine crushing, thanks to the variety of vessels available. There is a USB interface available for easy actuation and documentation respectively.
High performance
Excellent crushing performance is guaranteed by a combination of
variable rotational speeds, ranging from 3000 rpm to 20 000 rpm,
and a 1000 Watt output.
Interval operation
The option of interval programming is simple to activate at the
press of a button. Interval operation is an asset during the coarse
crushing of hard samples or for extra thorough blending.
Integrated cooling
A cooling system is integrated in the milling cup, which allows
indirect heat dissipation. Thus, coolant and sample remain separate.
TFT-display
A clear TFT-display guarantees user-friendly operation.
Temperature measurement
MultiDrive control offers temperature measurement and vessel
recognition using RFID. A temperature limit can be set for
temperature-sensitive materials, or for specific planned reactions to
protect against overheating.
Weighing function
The weighing function is also integrated into the user-friendly
workflow of the IKA MultiDrive control. Weighing is performed
before crushing using the same mixing cup, so that no transfer
of contents is required.
Package Includes:
- IKA MultiDrive control
- MultiDrive TC 1 Protective housing
- MultiDrive MT 150.5 Milling tube, autoclavable
Warranty: Comes with 2+1 Year Warranty. See details here
| Process type | batch |
| Operating principle | cutting/impact/blending/dispersing |
| Motor rating input | 1000 W |
| Motor rating output | 800 W |
| Speed range | 3000 - 20000 rpm |
| Speed deviation | ±5 % |
| Power-ON time | 5 min |
| Power-OFF time | 10 min |
| Motor principle | Brushless DC |
| Display | TFT |
| RFID reader/writer unit | yes |
| Temperature display | yes |
| Temperature measurement resolution | 0.1 K |
| Accuracy of temperature measurement | ±1 K |
| Temperature limit min. | -50 °C |
| Temperature limit max. | 120 °C |
| Monitoring maintain time | yes |
| Weighing function | yes |
| Weighing range | 5 - 4000 g |
| Weighing resolution | 1 g |
| Load capacity weighing function max. | 4 kg |
| Weighing accuracy | ±(0.3%+2) g |
| Vessels detection | yes |
| Ramp programming | yes |
| Dimensions (W x H x D) | 300 x 350 x 250 mm |
| Weight | 8.5 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 31 |
| USB interface | yes |
| Bluetooth interface | yes |
| Voltage | 100 - 120 V |
| Frequency | 50/60 Hz |
| Power input | 1000 W |
